HR-EHSA (Humidistat)

• Measurement
  Accuracy
  Operation span
  Operation method
  Capacity of microswitch
  Temperature
  Sensor type
  Dimension
  Power supply
  Power cord
• 10%-80%rH
  ±5%
  3%
  ON/OFF
  2.2A
  10℃-40℃
  Nylon Loop
  140Hx95Lx45W(mm)
  110V or 22V / 60Hz or 50Hz
  2m

Features

• No necessary of additional unit for installation
  Easy to use with its simple structure
  Manufactured to use for only one humidifier since the capacity of internal switch is only 2.2 ampere
  High durability and trouble free

Installation

• Fix the unit at 150cm of height from the floor ( There is a hole to fix on the reserve side of the case)

Operation

• Set the knob on the humidity level you want. If you set the knob on 70, the humidifier would stop at 70%rH and restart at 67%rH
